Background: The thalamic anteroventral nucleus (AV) is a promising target structure for deep brain stimulation (DBS) in patients suffering from refractory epilepsy. Direct visualization of the AV would improve spatial accuracy in functional stereotactic neurosurgery for treatment of this disease. Methods: On 3-tesla magnetic resonance imaging (MRI), acquisition parameters were adjusted for optimal demarcation of the AV in 1 healthy subject. Reliability of AV visualization was then evaluated in 5 healthy individuals and 3 patients with refractory epilepsy. Results: In all individuals, an adjusted T1-weighted sequence allowed for demarcation of the AV. It was clearly distinguishable from hyperintense myelin-rich lamellae surrounding it ventrally and laterally and appeared hypo-intense compared to the adjacent thalamic nuclei. Image resolution and contrast facilitated direct stereotactic targeting of the AV prior to DBS surgery in all 3 patients. Conclusions: Direct targeting of the AV can be achieved, which has immediate implications for the accuracy of MRI-guided DBS in patients with refractory epilepsy.

Keywords:
Thalamus, Anteroventral nucleus, Deep brain stimulation, Epilepsy, Magnetic resonance imaging
1.
Brunenberg EJL, Platel B, Hofman PAM, Ter Haar Romeny BM, Visser-Vandewalle V: Magnetic resonance imaging techniques for visualization of the subthalamic nucleus. J Neurosurg 2011;115:971-984.
2.
Mirski MA, McKeon AC, Ferrendelli JA: Anterior thalamus and substantia nigra: two distinct structures mediating experimental generalized seizures. Brain Res 1986;397:377-380.
3.
Mirski MA, Rossell LA, Terry JB, Fisher RS: Anticonvulsant effect of anterior thalamic high frequency electrical stimulation in the rat. Epilepsy Res 1997;28:89-100.
4.
Hodaie M, Wennberg RA, Dostrovsky JO, Lozano AM: Chronic anterior thalamus stimulation for intractable epilepsy. Epilepsia 2002;43:603-608.
5.
Hamani C, Ewerton FIS, Bonilha SM, Ballester G, Mello LEAM, Lozano AM: Bilateral anterior thalamic nucleus lesions and high-frequency stimulation are protective against pilocarpine-induced seizures and status epilepticus. Neurosurgery 2004;54:191-195, discussion 195-197.
6.
Kerrigan JF, Litt B, Fisher RS, Cranstoun S, French JA, Blum DE, et al: Electrical stimulation of the anterior nucleus of the thalamus for the treatment of intractable epilepsy. Epilepsia 2004;45:346-354.
7.
Hirai T, Jones EG: A new parcellation of the human thalamus on the basis of histochemical staining. Brain Res Brain Res Rev 1989;14:1-34.
8.
Morel A: Stereotactic Atlas of the Human Thalamus and Basal Ganglia. New York, Informa Healthcare, 2007.
9.
Schaltenbrand G, Wahren W: Atlas for Stereotaxy of the Human Brain, ed 2. Stuttgart, Thieme, 1977.
10.
Fisher R, Salanova V, Witt T, Worth R, Henry T, Gross R, et al: Electrical stimulation of the anterior nucleus of thalamus for treatment of refractory epilepsy. Epilepsia 2010;51:899-908.
11.
Wiegell MR, Tuch DS, Larsson HBW, Wedeen VJ: Automatic segmentation of thalamic nuclei from diffusion tensor magnetic resonance imaging. Neuroimage 2003;19:391-401.
12.
Gringel T, Schulz-Schaeffer W, Elolf E, Frölich A, Dechent P, Helms G: Optimized high-resolution mapping of magnetization transfer (MT) at 3 Tesla for direct visualization of substructures of the human thalamus in clinically feasible measurement time. J Magn Reson Imaging 2009;29:1285-1292.
13.
Traynor CR, Barker GJ, Crum WR, Williams SCR, Richardson MP: Segmentation of the thalamus in MRI based on T1 and T2. Neuroimage 2011;56:939-950.
14.
Mugler JP, Brookeman JR: Three-dimensional magnetization-prepared rapid gradient-echo imaging (3D MP RAGE). Magn Reson Med 1990;15:152-157.
15.
Wright SM, Wald LL: Theory and application of array coils in MR spectroscopy. NMR Biomed 1997;10:394-410.
16.
Wiggins GC, Polimeni JR, Potthast A, Schmitt M, Alagappan V, Wald LL: 96-Channel receive-only head coil for 3 Tesla: design optimization and evaluation. Magn Reson Med 2009;62:754-762.
17.
Bender B, Mänz C, Korn A, Nägele T, Klose U: Optimized 3D magnetization-prepared rapid acquisition of gradient echo: identification of thalamus substructures at 3T. AJNR Am J Neuroradiol 2011;32:2110-2115.
18.
Margerison JH, Corsellis JA: Epilepsy and the temporal lobes. A clinical, electroencephalographic and neuropathological study of the brain in epilepsy, with particular reference to the temporal lobes. Brain 1966;89:499-530.
