Use of Ventilation-Perfusion Single-Photon Emission Computed Tomography to Select the Target Lobe for Endobronchial Valve Lung Volume Reduction Open Access

Selecting the target lobe for endobronchial valve lung volume reduction (EBV-LVR) in severe emphysema can be challenging especially in patients with homogenous disease. Currently quantitative computed tomography (qCT) is the gold standard imaging to guide target lobe choice. qCT provides analysis of the lobar volumes, emphysema ratios, and fissure integrity. Homogenous emphysema is defined as a <15% difference in emphysema ratio between the target lobe and the remaining ipsilateral lobe [1-4].

Planar perfusion scintigraphy has a complementary role in target lobe selection especially in homogenous disease [4-6] where the qCT is unable to identify an obvious target. The target lobe in the IMPACT study by Valipour et al. [4] was chosen based on the highest emphysema ratio, absence of collateral ventilation, and the lowest perfusion on planar perfusion scintigraphy. The commonly used current method involves 2-dimensional quantitation of radioactivity in the anterior and posterior projections and segmenting the lungs into 6 symmetrical rectangular zones. A major limitation of this method is the lack of correlation with actual lobar anatomy, particularly in the setting of advanced emphysema.

With the advent of hybrid gamma cameras with CT, single-photon emission computed tomography (SPECT)/CT is now a frequently used method of 3-dimensional imaging in nuclear medicine, including for ventilation-perfusion (VQ) scans. Fusion of SPECT with CT allows for accurate qualitative evaluation of the physiological data of SPECT with the anatomical detail of CT. Quantitation with SPECT/CT however is not often performed due to associated technical complexities.

VQ SPECT/CT lobar quantitation programs are now commercially available from gamma camera vendors. These programs are capable of determining the percentage radioactivity of each lobe for the VQ SPECT scans. At our institution, we have independently developed an interactive data language (IDL)-based program of lobar quantitation of differential V and Q. This program, which we have termed the Royal Adelaide Hospital Ventilation Perfusion SPECT/CT Quantitation (RAHVQSQ), is capable of analysing data acquired as a SPECT with CT in a singular hybrid camera or with 2 separate datasets consistent with the SPECT from a gamma camera and a chest CT from another scanner. We have also devised a unique method of deriving an index from the percentages of V and Q radioactivity, and the percentage volume of each lobe. We have termed this index the ventilation perfusion differential index (VQDI).

We suspect the VQDI reflects the gas exchange capacity and thus has potential value of determining the degree of emphysema of each lobe. It could potentially provide the physiological equivalent of the emphysema ratio of qCT. With the exception of fissure integrity, all of the parameters needed for target lobe selection in EBV-LVR provided by qCT can be derived using RAHVQSQ.

Thus, the primary aim of our study was to validate that VQDI is a parameter of value for target lobe selection in EBV-LVR by evaluating the concordance with the current gold standard imaging test of qCT. Our secondary aim was to evaluate the effect of EBV-LVR on the VQDI of the treated and untreated lobes.

This study was a prospective, multi-centre, single blinded, observational study. This study was approved by the Royal Adelaide Hospital Human Research Ethics and Central Adelaide Local Health Network Governance (HREC/16/RAH/237 R20160624) and the Calvary Health Care Adelaide Human Research and Ethics Committee (16-CHREC-E007).

The recruited participants provided written informed consent and permission to publish. The participants were patients with severe emphysema who remained symptomatic despite maximum medical therapy and were referred for LVR. The inclusion criteria included an age of 40–80 years, diagnosis of emphysema including homogenous emphysema, a forced expiratory volume in 1 s (FEV1) of 15–50% of the predicted value, a total lung capacity of >100% of the predicted value, a residual volume (RV) of over 150% of the predicted value, and post-rehabilitation 6-minute walk distance (6MWD) of at least 140 m. The exclusion criteria included corrected carbon monoxide diffusing capacity (DLCOcorr) of <20% of the predicted value, hypercapnoea with a partial pressure of carbon dioxide of over 50 mm Hg, hypoxaemia with partial pressure of oxygen <45 mm Hg while breathing ambient air, giant bullae taking up >30% lung volume of target lobe, α1-antitrypsin deficiency, previous thoracotomy on target side, excessive sputum of >4 tablespoons per day), uncontrolled severe pulmonary hypertension (pulmonary artery pressure >50 mm Hg), active infection, unstable cardiac disease, lung nodule that requires further work-up to exclude malignancy and contraindications to VQ scan like egg allergy and pregnancy or potential pregnancy. All our subjects were screened at baseline with no co-morbidities as outlined in the exclusion criteria. These inclusion and exclusion criteria were based on publications from Herth et al. [7], Kloosters et al. [2], and Valipour et al. [4].

At enrolment, all participants had qCT chest and standard VQ SPECT along with completed St. George’s Respiratory Questionnaire (SGRQ). They also underwent standard physiological testing as per the standard protocol, including spirometry, gas transfer, static lung volumes, and 6-minute walk test (6MWT).

The participants had their imaging in various centres depending on the point of recruitment. Most of the CTs were performed on a Siemens Somatom Definition AS 128 detectors (Siemens Healthcare) with acquisition parameters of 120 Kv 85 mAs 100 DLP 200–300 mGy cm CTDi 5–10 mGy, acquired both in inspiration and expiration The quantitative analysis was performed on the Philips IntelliSpace Portal version 10.1 (Philips Healthcare). The CTs were formally reviewed by our thoracic radiologist who determined fissure integrity.

All of the VQ scans were performed on Hawkeye 4 (GE Healthcare). Standard protocol was applied with 40–50 MBq ^99mTc Technegas for the ventilation scan and 200–250 MBq ^99mTc-labelled macro aggregated albumin for the perfusion scan. Planar scans (3 min acquisition, 256 × 256 matrix) were acquired for both studies in the anterior and posterior projections, and segmental quantitation in 6 symmetrical rectangular zones was derived using geometric mean. SPECT scans were acquired for both studies (Matrix 128 × 128; rotation: 3.0, zoom 1; ventilation 13 s/step, perfusion 8 s/step; 120 views; Butterworth filter, threshold 0.48, power 10 and OSEM 2 iterations 10 subsets). If a low-energy CT was used, the acquisition parameters were 2.5 mA, 140 kV, DLP 125 mGy cm.

The SPECT and the diagnostic CT datasets were then used for lobar segmentation in the RAHVQSQ program, which is IDL-based version 6.3 software. In this program, the CT is displayed as a 3-dimensional map which can be freely rotated by the operator who determines the positions of the fissures by manual annotation (shown in Fig. 1). The program allows the free manipulation of the windowing of the CT to assist fissure identification. Our nuclear physician (CC) was the sole operator of this program for all studies. Once the fissures are localized, the program then fuses the CT map with the V and Q SPECTs and determines the percentage radioactivity of each scintigraphic study for each lobe. The results are displayed as a spreadsheet, and an example is depicted in Table 1. From the differential percentages of V and Q and volume of each lobe, the VQDI was determined.

The target lobe was selected at a multi-disciplinary team meeting attended by interventional pulmonologists, thoracic radiologist, nuclear physician, and occasionally thoracic surgeons. The panel made target lobe recommendations based on CT (CT_TL) using the following criteria, including fissure integrity as assessed by a thoracic radiologist and Chartis assessment to ensure absence of collateral ventilation, highest emphysema destruction ratio (percentage of voxels <950 HU), high target lobe volume, and emphysema heterogeneity – heterogeneous defined as absolute difference of 15% or greater in emphysema destruction ratio. Where the qCT showed homogenous emphysema (emphysema destruction ratio <15%), the target lobe was chosen on the basis of the planar perfusion scintigraphy results, in conjunction with other qCT parameters including the fissure integrity and lobar volume. The VQDI results were blinded to the panel (with the exception of the nuclear physician who generated the index and thus did not participate in the panel recommendations) and proceduralists during target lobe selection.

Post EBV-LVR procedure, the nuclear physician selected the target lobe based on de identified VQDI results (VQDI_TL) and fissure integrity information from qCT (as the RAHVQSQ cannot determine fissure integrity). He was blinded to all other data including the panel recommendations and treatment lobe. A target lobe was selected according to the lobe with the lowest or next lowest VQDI, heterogeneous emphysema defined by the substantial difference in VQDI between the target and the ipsilateral lobes, and the lobe with the largest volume as determined in the CT map (see column C in Table 1). A threshold difference in VQDI between the target and the ipsilateral lobe to define heterogeneous emphysema was not determined. If there were to be a choice between 2 equipotential target lobes, the one with the larger difference in target versus ipsilateral lobe VQDI was preferred. The planar VQ quantitation results were not used.

All participants underwent bronchoscopy placement of Zephyr EBV under general anaesthesia. Chartis assessments were performed in all participants to ensure the absence of collateral ventilation prior to EBV placement. Participants with collateral ventilation positive on Chartis were then excluded from the study.

All participants were followed up to 6 months in this study, in addition to their usual follow-up with their treating physician. At 3 months, qCT scan was performed to determine the target lobe volume reduction and to assess for lobar occlusion. Repeat bronchoscopy and valve replacement were performed if atelectasis was not achieved. VQ SPECT scan was repeated at 3 months from baseline or after the repeat procedure in some participants. The lung function test, 6MWT, and SGRQ were collected at 3- and 6-month follow-up.

The primary outcome was to assess the concordance of the target lobe selected based on the gold standard test, qCT (CT_TL), and VQDI_TL. The secondary outcomes were the changes of VQDI in the treated lobe and the ipsilateral untreated lobe at 3 months and to evaluate the association between the changes in DLCOcorr and VQDI.

The sample size was calculated based on the precision of the estimate, using Cohen’s kappa. A sample size of 12 is required to allow a 95% CI in the substantial or almost perfect range (lower 95% CI for kappa ≥0.65). So in 95 out of 100 cases, Cohen’s Kappa will fall between 0.65 and 1.00 which is substantial to almost perfect reliability. Statistical software used was R Project for Statistical Computing 3.4.3. The primary outcome was calculated by Kappa statistic. The effect of endobronchial valves on various measurements was assessed by comparing baseline and post-procedure values (3 and 6 months). The analysis was done as per protocol by using linear mixed-effects models to adjust for repeated measurement over time to avoid erroneous standard errors and p values due to the same patients being measured 2–3 times (correlation of outcomes within patients). Linear regression models were used to investigate the association between DLCO and VQDI. The statistical software used in the secondary outcomes analysis was SAS 9.4 (SAS Institute Inc., Cary, NC, USA).

Between November 2016 and May 2018, 25 participants were screened for study eligibility; 4 were excluded due to positive collateral ventilation on Chartis and 3 by way of infection by Burkholderia cepacia, Mycobacterium avium complex, and Pseudomonas aeruginosa. A total of 18 participants were recruited from 3 major centres – Royal Adelaide Hospital, The Queen Elizabeth Hospital, and Calvary Wakefield Hospital. Seventeen participants were followed up at 3 months and 15 participants at 6 months. One participant had a fall and sustained a neck of femur fracture, which led to a decline in his physical fitness, requiring nursing home placement and causing him to be lost to follow-up for reasons not related to his original airway disease. Another participant had an unexpected exacerbation of COPD from parainfluenza a few months post procedure despite lobar atelectasis. She was transferred to a nursing home and missed follow-up at 6 months due to worsening chronic pain from an abdominal hernia and worsening of her anxiety post hospitalization which was not related to her respiratory disease and could not be predicted at the time of screening. Another participant had the Zephyr valves removed before 6-month follow-up. This participant had recurrent exacerbations without pneumonia post procedure and had bronchoscopies showing mucous plugging within the valves with evidence of Aspergillus on the washing. A clinical decision was made to remove the valves as the quality of life score did not improve following a short course of anti-fungal treatment.

The mean age was 65 years with over half being female (55.6%); mean FEV1 32 ± 8% was predicted, consistent with very severe emphysema, and a mean RV of 200 ± 37% was predicted, consistent with severe gas trapping. There were 8 (44%) participants who had homogenous emphysema distribution (shown in Table 2).

There was high agreement between CT_TL and VQDI_TL lobe. A total of 16 out of 18 target lobes were concordant, with a concordance rate of 89% (Kappa = 0.85) Table 3. In one of the discordant cases, case A (shown in Tables 4 –4-6) qCT indicated homogenous emphysema and only the left lung oblique fissure was intact. Although the left lower lobe had the higher volume, the left upper lobe was chosen based on planar VQ results, with the left upper zone showing a lower perfusion (9 vs. 14%). Based on VQDI, there was higher heterogeneity between the left upper lobe and the left lower lobe than emphysema ratio from qCT, thus, in retrospect, justifying treating the left lung. However, the left lower lobe was the preferred target lobe with RAHVQSQ analysis because it had a lower VQDI (0.69 vs. 0.91). Despite achieving complete left upper lobar occlusion, this subject had no sustained treatment response beyond the 3 months with a fall in FEV1 and rise in RV. The DLCOcorr dropped at 6 months after initial improvement at 3 months and his symptoms worsened. Further retrospective review also showed that the destruction score was not particularly high on qCT, and this too could have contributed to the lack of sustained effect.

In the second discordant case, B, the right upper lobe was chosen because of the highest emphysema ratio on qCT and the right upper zone had the lowest perfusion on planar quantitation (Table 7). On RAHVQSQ analysis (Table 8), the left lower lobe was a better target with the lowest VQDI, higher heterogeneity, and equivalent volume. In this participant, volume reduction was not achieved and a repeat procedure was not possible due to patient clinical decline and he was lost to follow-up.

There was a 76% mean relative reduction of the target lobe VQDI following EBV-LVR at 3 months, from 0.59 ± 0.28 to 0.14 ± 0.30 and a mean difference (MD) of −0.45 (95% CI −0.62, −0.29, p < 0.0001), compatible with good atelectasis response to EBV-LVR. However, there were no statistically significant post EBV-LVR changes to VQDI in the ipsilateral untreated lobe (MD 0.11, p = 0.39), the overall contralateral lung (MD 0.02, p = 0.87), the counterpart lobe to the target lobe in the contralateral lung (MD −0.02, p = 0.87), and counterpart lobe to the ipsilateral untreated lobe in the contralateral lung (MD −0.03, p = 0.87) following the procedure at 3 months.

There was a significant improvement in diffusing lung capacity (DLCO) at 6 months with a MD of 3.75% (p = 0.04). The improvement was initially not significant at 3 months (MD 2.63%, p = 0.12).

The association between the change of DLCO and the VQDI of the target lobe and ipsilateral untreated lobe was not identified. Further analyses showed there was an association between the improvement in DLCO and the baseline VQDI of the contralateral lung counterpart lobe to the treated lobe (p = 0.024). In this counterpart lobe, for every 1 unit VQDI above the mean baseline (0.98 ± 0.46), there was an estimate of 18.5% increase in DLCO at 3 months post EBV-LVR (Estimate = 18.5, 95% CI 2.42, 34.67).

Statistically and clinically significant improvements from baseline were seen at both 3 and 6 months for FEV1, total lung capacity, RV, SGRQ score, and target lobe volume (shown in Table 9). The responder threshold for FEV1 was defined as a greater or equal to 100 mL increment from baseline [8]. There was an absolute mean improvement in FEV1 of 150 mL at 3 months (p < 0.001), with 8/16 (50%) participants classified as a responder. At 6 months, the mean improvement was 90 mL (p = 0.02), with 9/15 (60%) of the participants still classified as responders.

The responder threshold for RV reduction was defined as greater or equal to 430 mL [9]. At 3 months, 10/15 (66%) participants had a mean reduction in RV of 800 mL (p < 0.0001). The result was sustained at 6 months with a MD of 670 mL (p = 0.0003).

The responder threshold for target lobe volume reduction was defined as greater or equal to 350 mL [7]. Fourteen out of 16 (88%) participants were responders, achieving a mean reduction of 973 mL (p < 0.0001) at 3 months.

There was no significant difference in the mean 6MWD; however, 10/15 (67%) had a >26 m improvement in their 6MWD at 3 months and 8/11 (73%) achieved this minimal clinically important difference [10] at 6 months. The absolute and percentage changes from baseline at 3 and 6 months are summarized in Table 9, and the percentage of responders is summarized in Table 10.

The adverse events over 6 months are summarized in Table 11. There were 4 participants who required valve repositioning and another participant who had repeat bronchoscopy due to mucous plugging. One participant did not achieve atelectasis on follow-up imaging and achieved atelectasis following valve replacement. Two participants required valve replacement a few months post procedure due to partial re-expansion of the treated lobes on subsequent imaging, and they both achieved lobar collapsed following with valve replacement. Another participant had an episode of haemoptysis due to irritation from granulation tissue and subsequently 1 valve was removed and then reinserted 6 weeks post removal. Two procedure-related pneumothoraces occurred in 2 participants (11%), both occurring within 3 days and both requiring chest tube insertion with subsequent resolution of the pneumothoraces within 7 days. Three respiratory infections were reported including 1 participant who was found to have positive Aspergillus culture on repeat bronchoscopy requiring permanent valve removal before 6 months due to persistent infection and worsening symptoms compared to pre-treatment.

All previous studies [5, 11, 12] to investigate the role of perfusion scintigraphy in LVR procedures suffered from the same limitation of non-lobar segmentation of lung perfusion, that is, using 2 dimensional planar scans which roughly divides the 2 lungs into 6 equal rectangular zones. The middle zones were excluded for assessment as they included overlapping regions of the upper and lower lobes. Chandra et al. [11] and Argula et al. [12] contend that the target lobe should be the lobe with lowest perfusion.

We believe our study is the first to use VQ SPECT/CT lobar quantitation to determine the target lobe for EBV-LVR. Our lobar quantitation technique has refined the way to measure the VQ through anatomically defined lobes. Lobar quantitation with SPECT/CT software is currently commercially available. We have independently devised a program with a different approach that we found to be more intuitive and flexible to the operator in terms of delineating the locations of the fissures which we found helpful especially when the lungs are grossly disfigured and the fissures are deficient.

We have undertaken a unique approach to the analysis of results by considering both the V and the Q data, with each corrected for lobar volume, to create an index that we have called VQDI. We think the target lobe choice should not be based on perfusion scan alone as it is only half of the evaluation for gas exchange. This is relevant in advanced emphysema and is well demonstrated in a VQ scan whereby the heterogeneity of radioactivity in the ventilation scan can be drastically different from heterogeneity of radioactivity in the perfusion scan. There are often lobes which appear perfused but not ventilated on the scan. To assume such a lobe has equal value for gas exchange as another lobe with equivalent perfusion but significantly higher ventilation would be erroneous.

The main premise of our analysis is that it is important to know the concentration of air and concentration of blood in each lobe to assess the capacity of each lobe to perform gas exchange. Thus, the percentage radioactivity of each radiopharmaceutical was divided by the percentage volume. The absolute amount of radioactivity in each lobe can be misleading for target lobe determination because the volumes of the lobes are different. A small healthy lobe may have a lower absolute amount of radioactivity than a large diseased lobe.

In emphysema, there is gas trapping from the loss of lung compliance. The ventilation scan only demonstrates the inspired radioactive gas. The dead space appears photopenic or “cold” on the scan. For analysis of the amount of inspired air that is available for gas exchange, we estimated the “concentration of air” by dividing the percentage radioactivity of the ^99mTc Technegas by the percentage volume of the lobe.

In emphysema, there is shunting of blood away from diseased lobes in preference of the healthier lobes to maximize gas exchange. For analysis of the amount of blood that is available for gas exchange, we estimated the “concentration of blood” by dividing the percentage radioactivity of the ^99mTc macro aggregated albumin by the percentage volume of the lobe.

VQDI is a product of concentration of air and concentration of blood. It compares the degree of emphysema between the lobes by evaluating the combined effects of gas trapping and blood shunting. The worse the emphysema, the lower the index.

In this study, there is evidence of statistically significant subjective and objective improvement in the subjects who received our standard of care that used qCT with the assistance of planar VQ quantitation to determine the target lobe. Thus, qCT is a valid gold standard of imaging for this purpose. A very high concordance between VQDI and qCT supports the role of VQDI.

The principal aim of this study is verifying the value VQDI as a parameter for target lobe selection in EBV-LVR by comparing with the gold standard test of qCT. The intention of this study is not to evaluate VQDI as an alternative replacement for qCT. It is also not the intention of this study to evaluate if VQDI complements qCT. Nevertheless, in our clinical practice, the 2 techniques are complementary. To assess disease burden, qCT evaluates tissue density, whereas VQDI evaluates the combined effects of gas trapping and blood shunting. Applying both techniques adds to the confidence of target lobe choice, especially in homogenous emphysema. As illustrated in the first discordant case where the emphysema ratio was uniform (shown in Table 4) and only the left oblique fissure was intact, only the left lung could be the target for EBV-LVR. However, the RAHVQSQ analysis showed a significant VQDI heterogeneity between the left lower lobe and the left upper lobe, where the lower lobe had the lower VQDI (Table 5). If this participant was not recruited, the target lobe choice by our panel may have been different. Of note the second discordant case also did not achieve a sustained benefit. The potentially better clinical outcome with target lobe choice based on VQDI for the discordant cases is speculative and is beyond the scope of this observational study.

The effect of EBV on V and Q has been studied recently. The first pilot study by Chung et al. [13] using an Australian cohort of 8 patients underwent left upper lobe EBV treatment. Serial VQ SPECT perfusion scintigraphy was done at baseline, day 30 and 90. There was a significant reduction of both the V and Q in the treated lobe and the total left lung. They also found the right lower lobe and the overall right lung’s V and Q were increased. The reduction of ventilation in the treated lobe was consistent with the function of EBVs to achieve atelectasis, while reduced perfusion was thought to likely be due to hypoxic vasoconstriction in the same hypoventilated area, resulting in redistribution of perfusion to other lung regions. The likelihood of the left lower lobe (untreated ipsilateral lobe) decrease in perfusion could be due to the “dilution” effect from the compensatory hyperinflation.

Another study by Pizarro and colleagues [14] from Germany also found a significant reduction in target zone perfusion and ventilation of 26 patients at 8 weeks. They found the perfusion in the contralateral lung increased significantly by 5.96% (relative change, p = 0.005). Pizarro et al. [14] also found an association between the 6MWD responders (69.2% subject, based on at least 25 m improvement on 6MWD) who had both their perfusion and ventilatory changes reduced in the target lobe.

More recently, Hsu et al. [15] reported the VQ changes and gas transfer capacity corrected for alveolar volume, KCO of 11 patients. There were significant decreases in the V and Q activity of the targeted lung and increases in the non-targeted lung at 1 month. The trends were still observed at 12 months, but they were no longer statistically significant. Hsu et al. [15] also reported both the KCO and diffusing gas capacity DLCO improved at 3 months and at 12 months, but not at 1 month. Our study showed a statistically significant improvement in DLCO at 6 months. There was a recorded improvement at 3 months, but the difference did not reach statistical significance.

Using VQDI in our study has further confirmed the observation from reported studies showing significant reduction in the target lobe VQDI 3 months after EBV-LVR. However, we did not find a significant difference or pattern in the change of VQDI in the ipsilateral untreated lobe, overall contralateral lung, and the counterpart lobes to the treated and untreated lobes of the contralateral lung. There was a delayed improvement in DLCO which became more apparent after 6 months, suggesting a remodelling process following the VQ redistribution to the healthier and better functioning lobes and improvement in the VQ mismatch. Other possible explanations are reduction in the airflow obstruction and improvement of pulmonary hypertension.

In our study, we found an association between the baseline VQDI of the counterpart lobe to treated lobe in the contralateral lung and the DLCO. The higher the baseline VQDI the higher the likelihood of improvement in post EBV-LVR DLCO. This may be explained by an improvement in overall gas exchange in subjects with a healthier contralateral counterpart lobe.

There are several limitations of this study that should be considered. The study design was an observational study without a control group and a small sample size. The target lobe was chosen by the same nuclear medicine physician based on VQ SPECT, although this allows for consistent interpretation by having a reference nuclear physician experienced with the technique. The previous study by El-Barhoun et al. [16] has shown its reproducibility between and within 3 observers with high inter- and intra-observer concordance. Given the increased radiation exposure with VQ SPECT and CT chest, our study limited the repeated scans only at 3 months; the redistribution of VQ to the other regions of the lungs may be more apparent before or after 3 months. Future studies may be able to repeat the VQ scan at a later time frame that may provide additional scientific value.

In conclusion, our study has validated the value of VQDI derived from VQ SPECT/CT lobar quantitation by comparing it to the gold standard imaging of qCT for target lobe selection in EBV-LVR. In our practice, this functional imaging technique has a complementary role to qCT and adds confidence in target lobe choice. This is especially the case when qCT indicates homogenous emphysema with no clear lobar target. Future prospective randomized study is needed to evaluate the complementary role of the 2 imaging techniques.
