Background: To report the morphological macular findings detected by spectral domain optical coherence tomography (SD-OCT) and to determine their prevalence in patients with retinitis pigmentosa (RP). Methods: SD-OCT scans of 176 eyes from 90 patients affected by RP were reviewed. A careful evaluation was carried out on photoreceptor inner/outer segment (IS/OS) junction, external limiting membrane (ELM), inner limiting membrane thickening (ILMT), epiretinal membranes (ERMs), retinal micropseudocysts (MPCs), cystoid macular edema (CME), macular holes (MHs) and choroidal neovascularization (CNV). Results: The photoreceptor IS/OS junction was absent in the foveal region of 24 eyes (13.6%) and disrupted in 84 eyes (47.7%). The ELM was absent in 24 eyes (13.6%), whereas the ILMT was found in 118 eyes (67%). The presence of an ERM was detected in 48 eyes (27.3%). Some sort of vitreomacular alteration (ILMT and/or ERM) was identifiable in a total of 94.3% of eyes with RP. The presence of MPCs was detected in 32 eyes (18.2%). An evident CME was found in 22 eyes (12.5%). We also found MHs in 8 eyes (4.5%) and CNV in 3 eyes (1.7%). Conclusions: Our data indicate that RP is associated with alterations of many retinal layers. In particular, the vitreoretinal interface is affected in 94% of patients, and MPC can be identified in 18% of eyes. SD-OCT may contribute to the understanding of the pathophysiological mechanism involved in RP.

Keywords:
Retinitis pigmentosa, Photoreceptor junction, External limiting membrane, Inner limiting membrane thickening, Epiretinal membranes, Retinal micropseudocysts, Cystoid macular edema, Macular holes, Choroidal neovascularization
1.
Heckenlively J, Friederich R, Farson C, Pabalis G: Retinitis pigmentosa in the Navajo. Metab Pediatr Ophthalmol 1981;5:201-206.
2.
Bundey S, Crews SJ: A study of retinitis pigmentosa in the city of Birmingham. I. Prevalence. J Med Genet 1984;21:417-420.
3.
Bunker CH, Berson EL, Bromley WC, Hayes RP, Roderick TH: Prevalence of retinitis pigmentosa in Maine. Am J Ophthalmol 1984;97:357-365.
4.
Grøndahl J: Estimation of prognosis and prevalence of retinitis pigmentosa and Usher syndrome in Norway. Clin Genet 1987;31:255-264.
5.
Haim M, Holm NV, Rosenberg T: Prevalence of retinitis pigmentosa and allied disorders in Denmark. I. Main results. Acta Ophthalmol (Copenh) 1992;70:178-186.
6.
Hartong DT, Berson EL, Dryja TP: Retinitis pigmentosa. Lancet 2006;368:1795-1809.
7.
Lee SH, Yu HG, Seo JM, Moon SW, Moon JW, Kim SJ, Chung H: Hereditary and clinical features of retinitis pigmentosa in Koreans. J Korean Med Sci 2010;25:918-923.
8.
Hagiwara A, Yamamoto S, Ogata K, Sugawara T, Hiramatsu A, Shibata M, Mitamura Y: Macular abnormalities in patients with retinitis pigmentosa: prevalence on OCT examination and outcomes of vitreoretinal surgery. Acta Ophthalmol 2011;89:122-125.
9.
Hirakawa H, Iijima H, Gohdo T, Tsukahara S: Optical coherence tomography of cystoid macular edema associated with retinitis pigmentosa. Am J Ophthalmol 1999;128:185-191.
10.
Giusti C, Forte R, Vingolo EM: Clinical pathogenesis of macular holes in patients affected by retinitis pigmentosa. Eur Rev Med Pharmacol Sci 2002;6:45-48.
11.
Hajali M, Fishman GA, Anderson R: The prevalence of cystoid macular oedema in retinitis pigmentosa patients determined by optical coherence tomography. Br J Ophthalmol 2008;92:1065-1068.
12.
Grigoropoulos VG, Emfietzoglou J, Nikolaidis P, Chatzistefanou K, Vergados J, Theodossiadis GP, Theodossiadis PG: Optical coherence tomography findings in patients with retinitis pigmentosa and low visual acuity. Ophthalmic Surg Lasers Imaging 2010;41: 35-39.
13.
Aizawa S, Mitamura Y, Baba T, Hagiwara A, Ogata K, Yamamoto S: Correlation between visual function and photoreceptor inner/outer segment junction in patients with retinitis pigmentosa. Eye 2009;23:304-308.
14.
Wakabayashi T, Sawa M, Gomi F, Tsujikawa M: Correlation of fundus autofluorescence with photoreceptor morphology and functional changes in eyes with retinitis pigmentosa. Acta Ophthalmol 2010;88:177-183.
15.
Sheth SS, Rush RB, Natarajan S: Inner and outer retinal volumetric and morphologic analysis of the macula with spectral domain optical coherence tomography in retinitis pigmentosa. Middle East Afr J Ophthalmol 2012;19:227-230.
16.
Kim YJ, Joe SG, Lee DH, Lee JY, Kim JG, Yoon YH: Correlations between spectral-domain OCT measurements and visual acuity in cystoid macular edema associated with retinitis pigmentosa. Invest Ophthalmol Vis Sci 2013;54:1303-1309.
17.
Hikichi T, Akiba J, Trempe CL: Prevalence of posterior vitreous detachment in retinitis pigmentosa. Ophthalmic Surg 1995;26:34-38.
18.
Pruett RC: Retinitis pigmentosa. A biomicroscopical study of vitreous abnormalities. Arch Ophthalmol 1975;93:603-608.
19.
Pruett RC, Albert DM: Vitreous degeneration in myopia and retinitis pigmentosa. Bull Soc Belge Ophtalmol 1987;223:211-228.
20.
Vingolo EM, Giusti C, Forte R, Onori P: Vitreal alterations in retinitis pigmentosa: biomicroscopic appearance and statistical evaluation. Ophthalmologica 1996;210:104-107.
21.
Tremolada G, Pierro L, De Benedetto U, Margari S, Gagliardi M, Maestranzi G, Calori G, Lorenzi M, Lattanzio R: Macular micropseudocysts in early stages of diabetic retinopathy. Retina 2011;31:1352-1358.
22.
Spalton DJ, Bird AC, Cleary PE: Retinitis pigmentosa and retinal oedema. Br J Ophthalmol 1978;62:174-182.
23.
Uliss AE, Gregor ZJ, Bird AC: Retinitis pigmentosa and retinal neovascularization. Ophthalmology 1986;93:1599-1603.
24.
Chang GQ, Hao Y, Wong F: Apoptosis: final common pathway of photoreceptor death in rd, rds, and rhodopsin mutant mice. Neuron 1993;11:595-605.
25.
Portera-Cailliau C, Sung CH, Nathans J, Adler R: Apoptotic photoreceptor cell death in mouse models of retinitis pigmentosa. Proc Natl Acad Sci USA 1994;91:974-978.
26.
Xu GZ, Li WW, Tso MO: Apoptosis in human retinal degenerations. Trans Am Ophthalmol Soc 1996;94:411-430.
27.
Lohr HR, Kuntchithapautham K, Sharma AK, Rohrer B: Multiple, parallel cellular suicide mechanisms participate in photoreceptor cell death. Exp Eye Res 2006;83:380-389.
28.
Rohrer B, Pinto FR, Hulse KE, Lohr HR, Zhang L, Almeida JS: Multidestructive pathways triggered in photoreceptor cell death of the rd mouse as determined through gene expression profiling. J Biol Chem 2004;279:41903-41910.
29.
Paquet-Durand F, Johnson L, Ekström P: Calpain activity in retinal degeneration. J Neurosci Res 2007;85:693-702.
30.
Sancho-Pelluz J, Arango-Gonzalez B, Kustermann S, Romero FJ, van Veen T, Zrenner E, Ekström P, Paquet-Durand F: Photoreceptor cell death mechanisms in inherited retinal degeneration. Mol Neurobiol 2008;38:253-269.
31.
Marano F, Deutman AF, Leys A, Aandekerk AL: Hereditary retinal dystrophies and choroidal neovascularization. Graefes Arch Clin Exp Ophthalmol 2000;238:760-764.
32.
Iwakiri R, Okinami S, Hirata A: Two cases of retinitis pigmentosa associated with choroidal neovascularization (in Japanese). Nihon Ganka Gakkai Zasshi 2007;111:606-611.
33.
Malik A, Sood S, Narang S: Successful treatment of choroidal neovascular membrane in retinitis pigmentosa with intravitreal bevacizumab. Int Ophthalmol 2010;30:425-428.
34.
Battaglia Parodi M, De Benedetto U, Knutsson KA, Scotti F, Librando A, Bandello F, Iacono P: Juxtafoveal choroidal neovascularization associated with retinitis pigmentosa treated with intravitreal bevacizumab. J Ocul Pharmacol Ther 2012;28:202-204.
