Objective: To develop a novel optical probe monitoring cervical tissues in real-time and to compare the new imaging technique to actual cervical pathologic findings on resected cone biopsy specimens. Methods: A loop electro-excisional procedure was performed on 15 women with a biopsy diagnosis of dysplasia. The conization specimen was then assessed with the novel optical system and results recorded. The ‘normal' and ‘abnormal' areas were tested by the optical setup at several points. Extracted parameters were used as the input of the classifier function of a logistic regression algorithm model to assess for system accuracy vs. clinical examination. Results: Ninety-seven samples were taken - forty-five samples from ‘abnormal zones' and 42 samples from ‘normal zones', as defined by the surgeon. The pathologist diagnosed 58 samples as dysplastic and 39 samples as normal. The novel optical method predicted 58 sample points as abnormal and 39 points as normal. The sensitivity of the system was 90% with a specificity of 77%. The probability of correct differentiation of dysplastic cervical tissue from normal cervical tissue was 85%. Conclusions: The optical probe and the algorithms of image processing in combination with the logistic regression algorithm correlated well with pathology results for cervical dysplasia ex-vivo.

Keywords:
Cervical intraepithelial neoplasia, Colposcopy, Optics
1.
Janicek MF, Averette HE: Cervical cancer: prevention, diagnosis, and therapeutics. CA Cancer J Clin 2001;51:92-114; quiz 115-118.
2.
Sawaya GF, Brown AD, Washington AE, Garber AM: Clinical practice. Current approaches to cervical-cancer screening. N Engl J Med 2001;344:1603-1607.
3.
American College of Obstetricians and Gynecologists: ACOG practice bulletin number 66, September 2005. Management of abnormal cervical cytology and histology. Obstet Gynecol 2005;106:645-664.
4.
Arbyn M, Sankaranarayanan R, Muwonge R, et al: Pooled analysis of the accuracy of five cervical cancer screening tests assessed in eleven studies in Africa and India. Int J Cancer 2008;123:153-160.
5.
Jeronimo J, Schiffman M: Colposcopy at a crossroads. Am J Obstet Gynecol 2006;195:349-353.
6.
Mitchell MF, Schottenfeld D, Tortolero-Luna G, Cantor SB, Richards-Kortum R: Colposcopy for the diagnosis of squamous intraepithelial lesions: a meta-analysis. Obstet Gynecol 1998;91:626-631.
7.
Moss EL, Redman CW, Arbyn M, et al: Colposcopy training and assessment across the member countries of the European federation for colposcopy. Eur J Obstet Gynecol Reprod Biol 2015;188:124-128.
8.
Massad LS, Collins YC: Strength of correlations between colposcopic impression and biopsy histology. Gynecol Oncol 2003;89:424-428.
9.
Alvarez RD, Wright TC Jr; Optical Detection Group: Increased detection of high-grade cervical intraepithelial neoplasia utilizing an optical detection system as an adjunct to colposcopy. Gynecol Oncol 2007;106:23-28.
10.
Schomacker KT, Meese TM, Jiang C, Abele CC, Dickson K, Sum ST, Flewelling RF: Novel optical detection system for in vivo identification and localization of cervical intraepithelial neoplasia. J Biomed Opt 2006;11:34009.
11.
Wright TC Jr, Menton M, Myrtle JF, Chow C, Singer A: Visualization techniques (colposcopy, direct visual inspection, and spectroscopic and other visual methods). Summary of task force 7. Acta Cytol 2002;46:793-800.
12.
Nordstrom RJ, Burke L, Niloff JM, Myrtle JF: Identification of cervical intraepithelial neoplasia (CIN) using UV-excited fluorescence and diffuse-reflectance tissue spectroscopy. Lasers Surg Med 2001;29:118-127.
13.
Burke L, Modell M, Niloff J, Kobelin M, Abu-Jawdeh G, Zelenchuk A: Identification of squamous intraepithelial lesions: fluorescence of cervical tissue during colposcopy. J Low Genit Tract Dis 1999;3:49.
14.
Kendrick JE, Huh WK, Alvarez RD: LUMA cervical imaging system. Expert Rev Med Devices 2007;4:121-129.
15.
Bazant-Hegemark F, Edey K, Swingler GR, Read MD, Stone N: Review: optical micrometer resolution scanning for non-invasive grading of precancer in the human uterine cervix. Technol Cancer Res Treat 2008;7:483-496.
16.
Duraipandian S, Zheng W, Ng J, Low JJ, Ilancheran A, Huang Z: Near-infrared-excited confocal Raman spectroscopy advances in vivo diagnosis of cervical precancer. J Biomed Opt 2013;18:067007.
