Background: Percutaneous transhepatic biliary drainage (PTBD) plays a significant role especially in the palliation of an endoscopically inaccessible biliary system. Since a standard technique of PTBD is not defined, we compared a fluoroscopically guided technique (F-PTBD) with an ultrasound (US-PTBD) guided approach. Patients and Methods: Procedure characteristics, success-rates and complication-rates of the different PTBD techniques were compared in patients who underwent PTBD between October 1, 2006, and -December 31, 2014. Results: In 195 patients, 251 PTBDs (207 F-PTBDs, 44 US-PTBDs) were performed. F-PTBDs were mostly inserted from the right and US-PTBDs from the left. Patient age, gender and physical status were comparable in both techniques. There was no difference regarding overall procedure success (90%/86.4%), overall interventional complication rates (10.6%/9.1%), fluoroscopy times, intervention times or sedatives dosages. However, major complications were only encountered in F-PTBDs. There was a higher success rate for F-PTBD vs. US-PTBD from the right side (91.9 vs. 75%; p = 0.033) and a trend towards a higher success rate for US guidance from the left side (82.9 vs. 95.8%; p = 0.223). Conclusions: For drainage of the right biliary system F-PTBD seems superior over the US-PTBD technique used in this study. However, major complications can occur more frequently in F-PTBD.

Keywords:
Percutaneous transhepatic biliary drainage, Fluoroscopy, Ultrasound, Malignant biliary stricture, Complications
1.
Maaser C, Lenze F, Bokemeyer M, Ullerich H, Domagk D, Bruewer M, Luegering A, Domschke W, Kucharzik T: Double balloon enteroscopy: a useful tool for diagnostic and therapeutic procedures in the pancreaticobiliary system. Am J Gastroenterol 2008; 103: 894–900.
2.
Sarkaria S, Lee HS, Gaidhane M, Kahaleh M: Advances in endoscopic ultrasound-guided biliary drainage: a comprehensive review. Gut Liver 2013; 7: 129–136.
3.
Liu Y, Meng J, Wang J, Wang Z, Wang X, Linghu E, Li W, Yang Y: Repeated rendezvous treatment of PTBD and ERCP in patients with recurrent obstructive jaundice. Hepatogastroenterology 2010; 57: 1029–1033.
4.
Bapaye A, Dubale N, Aher A: Comparison of endosonography-guided vs. percutaneous biliary stenting when papilla is inaccessible for ERCP. United European Gastroenterol J 2013; 1: 285–293.
5.
Artifon EL, Aparicio D, Paione JB, Lo SK, Bordini A, Rabello C, Otoch JP, Gupta K: Biliary drainage in patients with unresectable, malignant obstruction where ERCP fails: endoscopic ultrasonography-guided choledochoduodenostomy versus percutaneous drainage. J Clin Gastroenterol 2012; 46: 768–774.
6.
Sharaiha RZ, Kumta NA, Desai AP, DeFilippis EM, Gabr M, Sarkisian AM, Salgado S, Millman J, Benvenuto A, Cohen M, Tyberg A, Gaidhane M, Kahaleh M: Endoscopic ultrasound-guided biliary drainage versus percutaneous transhepatic biliary drainage: predictors of successful outcome in patients who fail endoscopic retrograde cholangiopancreatography. Surg Endosc 2016; 30: 5500–5505.
7.
Dumonceau JM, Tringali A, Blero D, Devière J, Laugiers R, Heresbach D, Costamagna G; European Society of Gastrointestinal Endoscopy: Biliary stenting: indications, choice of stents and results: European Society of Gastrointestinal Endoscopy (ESGE) clinical guideline. Endoscopy 2012; 44: 277–298.
8.
Kühn JP, Busemann A, Lerch MM, Heidecke CD, Hosten N, Puls R: Percutaneous biliary drainage in patients with nondilated intrahepatic bile ducts compared with patients with dilated intrahepatic bile ducts. AJR Am J Roentgenol 2010; 195: 851–857.
9.
Oh HC, Lee SK, Lee TY, Kwon S, Lee SS, Seo DW, Kim MH: Analysis of percutaneous transhepatic cholangioscopy-related complications and the risk factors for those complications. Endoscopy 2007; 39: 731–736.
10.
Weber A, Gaa J, Rosca B, Born P, Neu B, Schmid RM, Prinz C: Complications of percutaneous transhepatic biliary drainage in patients with dilated and nondilated intrahepatic bile ducts. Eur J Radiol 2009; 72: 412–417.
11.
Wagner A, Mayr C, Kiesslich T, Berr F, Friesenbichler P, Wolkersdörfer GW: Reduced complication rates of percutaneous transhepatic biliary drainage with ultrasound guidance. J Clin Ultrasound 2017; 45: 400–407.
12.
Saad WE, Wallace MJ, Wojak JC, Kundu S, Cardella JF: Quality improvement guidelines for percutaneous transhepatic cholangiography, biliary drainage, and percutaneous cholecystostomy. J Vasc Interv Radiol 2010; 21: 789–795.
13.
Hatzidakis A: CIRSE Quality Improvement Guidelines for Percutaneous Transhepatic Cholangiography and Biliary Drainage. http://www.cirse.org/index.php?pid=755.
14.
Kozlov AV, Polikarpov AA, Oleshchuk NV, Tarazov PG: Comparative assessment of percutaneous transhepatic cholangiodrainage under roentgenoscopy and US guidance. Vestn Rentgenol Radiol 2002; 4: 30–33.
15.
Takada T, Yasuda H, Hanyu F: Technique and management of percutaneous transhepatic cholangial drainage for treating an obstructive jaundice. Hepatogastroenterology 1995; 42: 317–322.
16.
ASA Physical Status Classification System; Last approved by the ASA House of Delegates. https://www.asahq.org/resources/clinical-information/asa-physical-status-classification-system (October 15, 2014).
17.
Ring EJ, Oleaga JA, Freiman DB, Husted JW, Lunderquist A: Therapeutic applications of catheter cholangiography. Radiology 1978; 128: 333–338.
18.
Mayumi T, Someya K, Ootubo H, Takama T, Kido T, Kamezaki F, Yoshida M, Takada T: Progression of Tokyo Guidelines and Japanese Guidelines for management of acute cholangitis and cholecystitis. J UOEH 2013; 35: 249–257.
19.
Glenn F, Evans JA, Mujahed Z, Thorbjarnarson B: Percutaneous transhepatic cholangiography. Ann Surg 1962; 156: 451–462.
20.
Leng JJ, Zhang N, Dong JH: Percutaneous transhepatic and endoscopic biliary drainage for malignant biliary tract obstruction: a meta-analysis. World J Surg Oncol 2014; 12: 272.
21.
Makuuchi M, Bandai Y, Ito T, Watanabe G, Wada T, Abe H, Muroi T: Ultrasonically guided percutaneous transhepatic bile drainage: a single-step procedure without cholangiography. Radiology 1980; 136: 165–169.
22.
Sukigara M, Taguchi Y, Watanabe T, Koshizuka S, Koyama I, Omoto R: Percutaneous transhepatic biliary drainage guided by color Doppler echography. Abdom Imaging 1994; 19: 147–149.
23.
Lee W, Kim GC, Kim JY, Baik SK, Lee HJ, Kim HJ, Ryeom HK: Ultrasound and fluoroscopy guided percutaneous transhepatic biliary drainage in patients with nondilated bile ducts. Abdom Imaging 2008; 33: 555–559.
24.
Schmitz D, Grosse A, Hallscheidt P, Roseneck A, Niemeyer J, Rudi J: Color Doppler US-guided PTBD with and without metal stent implantation by endoscopic control: prospective success and early adverse event rates. Z Gastroenterol 2015; 53: 1255–1260.
25.
Rivera-Sanfeliz GM, Assar OS, LaBerge JM, Wilson MW, Gordon RL, Ring EJ, Kerlan RK Jr: Incidence of important hemobilia following transhepatic biliary drainage: left-sided versus right-sided approaches. Cardiovasc Intervent Radiol 2004; 27: 137–139.
26.
Jaques PF, Mandell VS, Delany DJ, Nath PH: Percutaneous transhepatic biliary drainage: advantages of the left-lobe subxiphoid approach. Radiology 1982; 145: 534–536.
